| Category | Description | Remarks |
| Cargo | Roll goods | |
| BasicData | ExternalDimensions | W1450 x 1960L x H1080mm | |
| Machine Weight | Max. 1300 Kg | |
| CargoWeight | Max. 1000 Kg | |
| LiftingHeight | 130mm | |
| Lift Type | Electric | |
| NavigationMethod | Laser SLAM | |
| MovementMethod | Twin-steer System | |
| ConnectionMethod | Servo Drive | |
| AdjustableAxialDirections | X,Y,Z.,θ, TILTING | |
| MovementCapabilities | TraverseSpeed | 0-1200mm/s | |
| Acceleration | 500mm/s² | |
| NavigationAccuracy | ±20mm | |
| ConnectionAccuracy | ±1mm | |
| SafetyFeatures | LaserObstacleAvoidance | 254° Arc, Max Detection Distance 20m | Install Height215mm |
| OpticalObstacleAvoidance | Zone: Horizontal 90°, Vertical 65.5°, Max Detection Distance 3m | Install Height408mm |
| AudioObstacleAvoidance | Zone: Horizontal 80°, Vertical 34°, Max DetectionDistance 1m | Install Height340mm |
| MechanicalCrash Guard | Installed | |
| EmergencyStop | Installed | |
| BatteryCapabilities | Battery Type | LiFePO4 48V 100Ah | |
| Uptime | 3h Charge per 8h Work | |
